Beautifully crafted with striking lines providing comfort and open space

The perfect RIB for demanding professional or leisure boaters

The 480/580 models have an ultra-strong double floor, molded back seating design as well as huge watertight storage compartments with comfortable cushions. Different seating options are available to fit all specific needs (Bow rider, Jockey seats, and additional seats).

Built in Pennel Orca® 828, unmatched quality Hypalon
material for superior resistance and longer life.

ModelCRB/SSMX-480/0
Overall Length4.8m (15'7")
Overall Width2m (6'6'')
Passengers7.5
Approx. Wg.338.6kg (746Lb)
Max Load*900kg(1984Lbs)
Outboard Max HP50hp (long shaft 20")
Inside length3.2m (10'6")
Inside Width1m (3'3'')
Tube diameter50cm (19.7")
Air-Chambers 4
Orca type 828
ModelCRB/SSMX-580/0
Overall Length5.78m (18'10")
Overall Width2.5m (8'2'')
Passengers11
Approx. Wg.468.6kg (1033Lb)
Max Load*1200kg(2646Lbs)
Outboard Max HP115hp (long shaft 20")
Inside length4.03m (13'3")
Inside Width1.3m (4'3'')
Tube diameter60cm (23.6")
Air-Chambers 5
Orca type 828

* Loaded weight should include everything except hull.
** 25hp engine is allowed when the boat is set up with console.
All the specifications on this sheet are CE certified.

We use two types of Hypalon:

Orca® 215 – PES: 100dtex Textile – 880 g/m2 and
Orca® 828 – PES: 100dtex Textile – 1300 g/m2
